Metrology

The success of your measurement depends strongly on the components you use in your system. We can provide products designed specially for your setup.



When precision matters

Requirements for high precision are exceptionally stringent in metrology. Even small deviations in the mechanical structure reduce the accuracy of the subsequent measuring value considerably. We are aware of this fact and deliver approved systems of highest quality. With our specially developed positioning solutions we pay attention to perfect straightness, the smallest deviations in yaw and pitch, as well as a smooth positioning movement.

Quality that can be measured

Our customers rely on us. Steinmeyer Mechatronik pays particular attention to the precise quality control of every system we deliver. Our modern metrology laboratory is equipped with up to date optical measuring systems. This guarantees the quality that our customers expect.

Products used in Metrology

XY stage with stepper motors and an aperture of 90 x 90 mm for varied positioning applications.
Open-frame stage with large aperture and powerful direct drives.
The XY stage is suitable for long travel distances and is primarily used for measuring applications.
The XY stage is suitable for long travel distances and is primarily used for measuring applications.
Linear axis for travel distances from 250 mm to 750 mm. Driven by a ironless, dynamic linear motor.
Compact linear axis for horizontal oder vertical applications. Equipped with a DC motor.
Micro stage for demanding environments. Equipped with precision cross roller bearings and piezo motor.
Micro stage with cross roller bearings and Piezo LEGS® motor for demanding environments.
Micro stage with compact design. Equipped with cross roller bearings and internal DC motor.
Micro stage with compact design. Equipped with cross roller bearings and internal stepper motor.
Micro stage with cross roller bearings and piezo motor for steps in nanometer range.
Micro stage for high precision applications. Driven by a DC Motor.
Micro stage for high precision applications. Driven by a stepper motor.
High precision linear stage with a width of 160 mm. Driven by ball screw and DC motor.
High-precision linear stage with a width of 160 mm. Driven by a ironless direct linear motor.
High precision linear stage with 160 mm width. Driven by ball screw and stepper motor.
